The Fiamma Garage Standard Carry-Bike 02096A54A is for installation on motorhomes with garage facility and can carry up to three bikes with a maximum loading weight of 50kg.
To install, the bike carrier’s lower section fastens to the garage floor and the Bike-Block is fixed to the wall or roof.
This bike carrier is delivered as standard with two Rail Quick Pro bike rails, 1 Bike-Block Pro 1 and one Bike-Block Pro 3 which will carry two bikes. An additional bike rail can be added to carry three bikes (supplied separately).
This updated version of the Garage Standard features black elements as opposed to the old traditional red version.
- Horizontal wheelbase (distance between brackets): 80cm
- Dimensions: 128 x 45cm (with rail support base in standard open position and in models with minimum adjustable vertical wheelbase).
Specifications
| Dimensions | 128 x 45cm |
| Replaces | Fiamma 02093A54A (Nova 12242) |
| Brand | Fiamma |
| Height Description | 1300mm |
| Width | 130mm |
| Depth | 530mm |
| Weight | 4.8kg |
| Colour | Aluminium |
| Maximum Load Description | 50kg |
| Application | Motorhomes |
| Position | Garage |
| Capacity Description | 2 Bikes as standard (Maximum 3 Bikes) |
| Supplied With | Bike-Block Pro 1, Bike Block Pro 3, 2 x Rail Quick Pro, Brackets |
| Optional Extras | Bike-Block Pro 2, 1 x Rail Quick Pro |
| Country of Origin | Italy |
Key Features
- Restyled 2023 model
- Keep bicycles secure in the motorhome storage compartment
- Easy to install
- Bike-Block to securely lock the bike
- Sturdy rails with reinforced base delivered with Quick-Safe straps
- Quick Lock quick and safe locking of the wheel to the rail
Click Here for the User's Manual
The Fiamma Carry-Bike Garage Standard comes standard to carry two bikes which can be upgraded to carry three bikes with an additional rail and support.
To upgrade the carry-bike to carry a 3rd bike, add the following -
